Model Generation Workflows

There are several routes from raw imagery to a working model in VIAME. They differ mainly in how much annotation the user does by hand, and in how good the resulting model can become. They are not exclusive: most projects start with a quick route and move towards the first workflow as annotations accumulate.

The workflows apply regardless of the type of annotation: detection boxes, masks, tracks, keypoints and so on. Only what is drawn, and the model trained from it, changes.

Comparison

Workflow	Annotation effort	Data needed	Resulting model
Deep learning from scratch	Highest, every object is drawn by hand	Hundreds of examples per class	Best, given enough data
Deep learning with partial automation	Moderate, the user corrects what a detector proposes	Hundreds of examples per class	Same as above, reached sooner
Video search with feedback	Low, the user accepts or rejects results	A few examples to start	Good for the amount of data, below a well trained deep model
Text queries (extension)	Low, the user types a description and corrects the results	None to begin	Initial annotations rather than a model

Workflow 1: Deep Learning from Scratch

1. Load up imagery in annotator
2. Annotate imagery manually
3. Export detection or tracks files
4. Repeat for as many sequences as possible in diverse backgrounds
5. Run model training
6. Evaluate model performance
7. Repeat steps 4 thru 6 as desired on detector fail cases, focusing additional annotation on sequences with the most errors

Pros:

• Models perform better than most other solutions when trained with enough training data.
• The annotations are made to the user’s own definition of each class, with no bias from an existing detector.
• The same annotations can be reused to train any detector, tracker or classifier later.

Cons:

• Requires a large amount of training data and user time to generate it.
• Performance is poor until enough examples of each class exist, so rare classes lag behind common ones.
• Needs a GPU for every detector other than the SVM.

Use this when accuracy matters most and annotation time is available, or when no existing detector finds the objects at all. See detector training.

Workflow 2: Deep Learning with Partial Automation

1. Load up imagery in annotator
2. Run an automated detector (can be one made by video search, default model, other pre-trained detector, or user generated deep detector)
3. Correct and export detection or tracks files
4. Repeat for as many sequences as desired in diverse backgrounds
5. Run model training
6. Evaluate model performance
7. Repeat steps 2 thru 6 as desired on detector fail cases

Pros:

• Can speed up annotation if automated detector is decent enough.
• Each retrained model makes the next round of annotation faster, since there is less to correct.
• Reviewing detector output shows where the model fails, which points to the imagery worth annotating next.

Cons:

• If automated detector is poor it can take more effort to correct automated outputs instead of doing annotations from scratch.
• Objects the detector misses are easy to overlook during review, so its blind spots can carry over into the next model.
• Box placement follows the detector’s habits, which may differ from how the user would have drawn them.

Use this once any detector finds most of the objects of interest, including a generic one that only proposes boxes without naming the species. See object detection.

Workflow 3: Video Search with Feedback

Video search with feedback starts from an example of what the user is looking for. The user then accepts or rejects the results the system returns. A simple model is trained from those answers.

1. Create searchable index for a video archive (either at full frame level, detection level on top of pre-trained detectors, or track level)
2. Launch search GUI
3. Use search GUI to generate (.svm) models from the accepted and rejected results
4. Save models to category directory
5. Evaluate models

Pros:

• Can be done with very little user effort, mostly computer runtime.
• Can be used to rapidly generate models for new classes.
• The resulting SVM models train and run on a CPU.

Cons:

• GUI generally crashes after about 6 iterations due to memory issues.
• Models generally not as good as deep models trained on enough training data (but can be better for cases with not a lot of training data).
• The archive has to be indexed before searching, which takes computer time up front.
• When the index is built on detections, a model can only find objects the underlying detector proposed a box for.

Use this for a new class with few examples, or to find rare objects in a large archive. Its results can also be corrected and used as annotations for the first two workflows. See video and image search.

Extension: Text Queries for Rapid Annotation

A text query finds objects from a description in words, such as “fish” or “sea turtle”. It needs no annotations, no index and no trained model, so it is the quickest way to get a first set of annotations on new imagery. It is best seen as a faster start to the second workflow than as a way to produce a final model.

1. Load up imagery in annotator
2. Run a text query pipeline, giving a description of the objects
3. Correct the results and assign the classes of interest
4. Export detection or tracks files
5. Run model training on the corrected annotations
6. Evaluate model performance

Pros:

• Nothing has to exist beforehand: no annotations, index or trained detector.
• SAM3 queries return masks and tracks as well as boxes, which are the slowest annotations to draw by hand.
• A vision-language model accepts longer descriptions, which helps pick out objects by appearance or behaviour.

Cons:

• Works best for categories that can be named simply. Telling apart similar species usually still needs a trained model.
• Slower per frame than a trained detector, and SAM3 requires a GPU.
• Vision-language model results carry no confidence, so they cannot be filtered by a threshold and all need review.
• Depends on an add-on or a separately served model being installed.

Try this at the start of a project, or for a new class that no detector covers, and keep it when correcting its results is quicker than annotating by hand. Once the corrected annotations are trained into a standard detector, that detector is faster and more accurate on the same imagery than the text query that started it. See text query and VLM.

Choosing a Workflow

Before annotating anything, run the existing models in the model zoo and add-ons on a sample of the imagery, and try a text query on it as well. If correcting the output of either is quicker than drawing the annotations by hand, continue with partial automation. If neither saves time, fall back to manual annotation or video search with feedback, depending on how much time there is to devote to the problem: manual annotation takes the most and gives the best model, video search with feedback takes little and gives a model that is good for the effort.

Situation	Suggested start
New imagery, nothing annotated yet	Try existing models and text queries on a sample, and keep whichever saves annotation time; falling back to manual annotation or video search depending on how much time you have to annotate
An existing model or text query finds most of the objects	Partial automation
Neither helps, and annotation time is available	Deep learning from scratch
Neither helps, and time is short	Video search with feedback
A rare object in a large archive	Video search with feedback
A handful of examples of a new class	Video search with feedback, or the SVM trainer
Hundreds of annotations per class available	Deep learning, from scratch or with partial automation

Whichever route is taken first, the corrected annotations it produces can be fed into detector training. As the number of annotations per class grows, retraining with a deep detector gives the largest gain in accuracy.
